Specification：22mm*50mm
H-22-AB 360° Rotation Mount
$13.60
Similar products
- TAMH Series Ø2-Inch Three-Axis Adjustment Mounts
- FWO-A2 Dual-Wheel Filter Wheel
- PJ30-A Series Post Mount Beam
- S/N0002_3 Universal Joint
Compatible accessories
- Heat-resistant Focusing Lens Focal Lens Plastic Lens 200℃ for 200-500mW Laser
- Heat-resistant Collimating Lens Focusing Lens Plastic Lens 200℃ for <500mW Laser
- Laser Beam Homogenizer / Optical Diffuser Lens Divergence Angle 9° for Red Green Laser
- Laser Alignment Card Double-frequency Card IR Detection Display Card 900-1100nm
Related categories
Description
Product Description
- Designed for installing 12mm stainless steel support rods.
- Combined AB axes with 360° flexible rotation function.
- Equipped with built-in M6 set screws to fix the rod and prevent displacement.
- M4 manual fixing screws at the AB interface for positioning.
The H-22-AB rotation mount features aluminum capped set screws, which are used to fix the rod and the adjusted angle. One end of the A-axis is fixed to the vertical rod, and the B-axis, fitted with a 12mm support rod, can be rotated freely to the desired angle and tightened.
Technical Description
The H-22-AB rotation mount features aluminum capped set screws, which are used to fix the rod and the adjusted angle. One end of the A-axis is fixed to the vertical rod, and the B-axis, fitted with a 12mm support rod, can be rotated freely to the desired angle and tightened.
Assembly
Manual assembly and installation
Installation Method:
Oeabt offers a variety of optomechanical accessories, suitable for studs, mounts, lens sleeves, RMS threads, camera mount threads, M25 threads, SM1 threads, microscopes, fiber optic connectors, collimators, aspheric lenses, 35mm bayonets, cage systems, mounting rods, support bases, and structural rails.
Engineering Drawing Download
Additional information
| Weight | 0.0483 kg |
|---|---|
| Diameter | |
| Optic Type |
