658nm 660nm Red Laser Diode Module Buck Drive Circuit Constant Current

Description

658nm 660nm Red Laser Diode Module Buck Drive Circuit Constant Current

The circuit board is a precision component. After receiving the package, it supports 7 days without reason to return the product without opening the original package. After the original package is opened, no return is provided. After sale, please consider whether you have the ability to install it manually before purchasing. Do not purchase if you do not have the ability to install! Our company does not provide trial play/trial loan/trial service. Thank you for understanding!

Parameters
Circuit control: Buck circuit, constant current, to ensure stable output after 4.7-8V power supply
Dimensions: 10.322mm6.1mm (widthlengthheight) (PCB thickness 1.0mm, total height 6.1mm)
Input Voltage:4.5-9V
Output current: <150mA ( If output current is 2A, 1R0 resistance needs to be reduced)
Output Voltage:4.7-8V
Reverse connection protection: because the input terminal is protected, the reverse connection is not energized.
Pin definition: The pad is specially designed for the 658nm driver board. You only need to arrange the pins in a triangle and solder them naturally.
Application: Mainly used for high-end laser tube drivers with 12V input, such as 12V car laser lights, optical instruments, etc.
