Description
500mW Laser 520nm Laser Head Green Laser Module
Product parameters
（1）Laser wavelength：520nm
（2）Output power：500mW
（3）Output stability：±5%
（4）Safety level：Class 4
（5）Spot shape：Line
（6）Divergence angle：≤3mrad
（7）Lens material：Optical focal lens
（8）Wire length：250mm
（9）Power board input voltage：DC 12V
（10）LD Input voltage：5V
（11）LD Input current：2A
（12）Modulation mode：TTL
（13）TTL trigger mode：>DC 2.0V
（14）Working frequency：≤30KHz
（15）Ambient temperature：-10~40℃
（16）Product size：303050mm
（17）Product weight：245g
（18）Service life：>8000 hours
